Card PCI Express Controller Card Combo 3x 1394b + 1x 1394a Firewire TI Chipset XI02213

Card PCI Express to 2 Port RS232 Serial Cắm Được Cho Các Slot Sau:

Slot PCI Express x1 - Slot PCI Express x8 - Slot PCI Express x16

Product name：    Combo 2x 1394b + 1x 1394a Firewire Ports PCI-Express Controller Card, TI Chipset,Support Low Profile Bracket
Product model：    MM-PCE2213-2B1A
Product description：    Specifacation
 •    Ports:
o    2x 1394b (9-pin, Bi-lingual)
o    1x 1394a (6-pin)
•    Supports Data Transfer Rates of:
o    100Mbps
o    200Mbps
o    400Mbps
o    800Mbps
•    TI Chipset
•    No Driver required (plug-and-play)
•    Simultaneous Operation of Multiple High-performance Devices
•    Supports Hot-swapping and Plug-n-Play Connection of Peripheral Devices
•    Works with Various Types of FireWire 800 (1394b) and 1394a Devices Including Portable Hard Disk, DV Camcorder, Digital Camera, CD-RW/DVD-ROM Drive and Other Audio/Video Devices
•    1-Lane (x1) PCI-Express with Transfer Rate 2.5Gb/s Full Duplex Channel
•    Support Provisions of IEEE P1394b Revision 1.33+
•    Compliant with PCI-Express Revision 1.0a
•    Compliant with IEEE 1394 OpenHCI Specifications V1.0 and V1.1
•    Compliant with IEEE 1394-1995 for a High Performance Serial Bus
•    Compliant with IEEE 1394a-2000 Standard
•    Fully Backward Compatible to 1394a Specification
•    Fully Interoperable with FireWire, iLink, and SB1394 Implementation of IEEE 1394 Standard

Specifications

General

Serial Communication

Driver Support

Regulatory Approvals

Giao tiếp với các thiết bị sử dụng RS-232

Agilent 34970A Data Acquisition/Switch Unit:
Baud Rate: 57600 (selectable)
Data bits: 8 (selectable)
Parity: None (selectable)
Start bits: 1 (fixed)
Stop bits: 1 (fixed)
Flow control: XON/XOFF

Agilent 34401A Digital Multimeter:
Baud Rate: 9600 (selectable)
Data bits: 8 (selectable)
Parity: None (selectable)
Start bits: 1 (fixed)
Stop bits: 2 (fixed)
Flow control: DTR/DSR (fixed)

Agilent 33120A Function Generator/Arbitrary Waveform Generator:
Baud Rate: 9600 (selectable)
Data bits: 8 (selectable; use this setting to download arbitrary waveforms)
Parity: None (selectable; use this setting to download arbitrary waveforms)
Start bits: 1 (fixed)
Stop bits: 2 (fixed)
Flow control: DTR/DSR (fixed)

Agilent 33250A Function Generator/Arbitrary Waveform Generator:
Baud Rate: 57600 (selectable)
Data bits: 8 (selectable; use this setting to download arbitrary waveforms)
Parity: None (selectable; use this setting to download arbitrary waveforms)
Start bits: 1 (fixed)
Stop bits: 1 (fixed)
Flow control: DTR/DSR (use any flow control, except XON/XOFF, to download arbitrary
waveforms)

RS-232 Configuration at the EPM-E Series Power Meter

The table below outlines the RS-232 configuration at the E4418B/E4419B power meter.

Type    Setting
Remote Interface - Select Interface    RS232
Remote Interface - Command Set    SCPI
Remote Interface - Configure Interface    Serial
Baud Rate    9600
Word Size    8
Stop Bits    1
Parity    None
1 of 2    To Next Page Configuration
Pacing    Tx Pacing Xon
Rx Pcaing Xon
RTS/CTS OFF
DTR/DSR OFF
