Cáp 3M 10ft MV-ACP-H6P-Open-ST-3M Power & I/O Cable Connector Hirose HR10A-7P-6S(73) 6 Pin Female to 6 Core Open For Industrial Camera Power Trigger I/O Signal Cable

Hikrobot MV-ACP-H6p-open-ST-3m Machine Vision Cable

Connector Hirose HR10A-7P-6S(73) 6 Pin Female

6 Core Open End

Wiring Diagram Cable ACC-01-3010 Cable Power Trigger I/O Signal Control Connector Hirose HR10A-7P-6S(73) 6 Pin Female to 6 Core Open End

MV-ACP-H6P-Open-ST Cable For use with: Blackfly GigE/Blackfly S GigE/Blackfly USB3/Blackfly S USB3/Forge

Brand: China/Original HIKROBOT Industrial Camera
Specifications
Model: MV-ACP-H6P-Open-ST-3M
Type: 6-pin P7 Standard Power & I/O Cable
Connector 1: Industrial Camera Hirose HR10A-7P-6S73 6 Pin Female
Connector 2: 6 Core Open End
Number of Conductors: 3-Pair
Connector Plating: Gold - Hirose HR10A-7P-6S(73)
Cable Jacket Material: Low Smoke Zero Halogen
Cable Shield Material: Aluminum-Mylar Tape with Braid
Operating Temperature: -20°C to 80°C
Jacket Material: PVC (Polyvinyl Chloride)
Gender: Hirose HR10A-7P-6S73 6 Pin to 6 Core Open End
Wire Gauge (AWG): 28 AWG
Jacket Material: PVC
Cable Style: Round
Wire Diameter (mm): 6.5mm
Cable E203693 AWM 2464 VW-1 24AWG*6C+FAE 7/0.30 80°C 300V OD: 6.5 mm PVC Jacket, black
Shielding: Yes
Length : 3M
Color: Black
Pin-Out: Hirose HR10A-7P-6S(73) 6 Pin Female: 1 - (Đỏ) / 2 - (Nâu) / 3 - (Cam) / 4- (Tím) / 5 - (Xanh) / 6 - (Đen) / Shell - (Heat Shrink Tubing Black) Connection
Cáp 3M 10ft MV-ACP-H6P-Open-ST-3M Power & I/O Cable Connector Hirose HR10A-7P-6S(73) 6 Pin Female to 6 Core Open For Industrial Camera Power Trigger I/O Signal Cable
