Nhân Điện Thoại RJ11 Modular Jack Cat3 AMP 1375192-1

AMP CAT3 MODULAR JACK, UNSHIELDED (1375192-1)
Mã sản phẩm : 1375192-1
AMP Category 3 Modular Jack, Unshielded, RJ11/14/25C, SL, Almond (part number :1375192-1) (ASSY, SL110JACK, C3, LT ALMOND)

AMP Category 3 Modular Jack, Unshielded, RJ11/14/25C, SL, Almond (part number :1375192-1)
(ASSY, SL110JACK, C3, LT ALMOND)

·         Connector Style Jack
·         Shielded No
·         Performance Category Cat 3
·         Jack Type RJ11 / RJ14 / RJ25
·         Dust Cover Without
·         Product Type Connector - Modular
·         Applies To Panel
·         Connector Type Connector Assembly
Configuration Features
·         Port Configuration Single
·         Jack Configuration 1 x 1
·         Keyed No
·         Number of Positions 6
·         Wiring Pattern USOC
Body Features
·         Inverted Jack Face Yes
Contact Features
·         Contact Base Material Beryllium Copper
·         Contact Mating Area Plating Material Gold
·         Contact Mating Area Plating Thickness 1.27 µm [ 50 µin ]
Termination Features
·         Termination Style SL Termination Tool
·         Termination Method to Wire/Cable Insulation Displacement Crimp (IDC)
Housing Features
·         Housing Color Light Almond
·         Housing Material Polycarbonate
Dimensions
·         Conductor Outside Diameter 1.45 mm [ .057 in ]
·         Solid Wire Range (AWG) 24 – 22
·         Stranded Wire Range (AWG) 26 – 24
Industry Standards
·         UL Flammability Rating UL 94V-0
